TDI Capabilities



The K-State Technology Development Institute has a wide range of production level manufacturing equipment in house. This equipment is used for both prototyping as well as small volume production when quantities are too low to be of interest to larger manufacturers. TDI works with it clients to design and produce products using today's most cutting edge production equipment to ensure that transitioning into large scale manufacturing is a simple process.

The video below provides a quick virtual tour of the equipment contained in the machining and fabrication studio:







	Bodor P3015T Fiber Laser	6kW laser generator capable of cutting 3/4” steel and 1/2” aluminum Dual 5’ x 10’ exchange tables 7” diameter tube capacity
	OMAX 60120 Waterjet	5 axis head allows cuts up to 60 degrees off vertical 5’ x 10’ bed Cuts a wide variety of materials
	RMT B-Genius 10-200 Press Brake	200 tons with 10’ bed Automatic crowning compensation 5 axis back gauge Bend 1/2” steel capacity
	HAAS UMC1000SS Meltio Hybrid	40” x 20” x 20” work envelope 30 hp up to 12,000 rpm Metal 3D printing with 1200W laser head to process 0.8-1.2 mm DIA wire feedstock
	HAAS UMC500SS Universal Machining Center	X-Axis- 24”, Y-Axis- 16”, Z-Axis- 16” 15.7 diameter platter 30hp up to 12000 rpm
	HAAS VF-6SS Vertical CNC Machining Center	X-Axis- 64”, Y-Axis- 32”, Z-Axis- 30” 64” x 28” with a 4000lb capacity 30hp up to 12000 rpm
	HAAS ST-25Y CNC Lathe	Y-Axis and Live Tooling 3” bar capacity 22.5” max cutting length
	IPG 2000XR Fiber Laser Welder	2000 watts of laser power Welds multiple materials including stainless steel and aluminum

Other capabilities include: Knuth Turnado280/1500 Manual Lathe, Knuth ABS 300 Vertical Cut Off Saw, Bridgeport Knee Mill, Acer Lathe, 50 ton Piranha Ironworker, MIG/TIG Welding and Oxy-Acetylene Cutting Torch, Modular Welding Table & Fixtures, Sand Blast Booth, Parts Washer, Vibratory Deburring Machine, Powder Paint Booth, and other machining and fabrication
equipment
